Aukey BR-O8 - Bypass Mode

Connect an audio source device (TV, computer, DVD player, CD player, or MP3
player) to the BR-O8 3.5mm audio input or optical input with the included 3.5mm
audio cable or optical cable
Connect your wired audio equipment (wired headphones, speaker, or stereo
system) to BR-O8 3.5mm audio output or optical output with a 3.5mm audio cable
or optical cable
Connect the BR-O8 to a power source with the micro-USB cable
Slide the Power/Mode switch to “BYPASS” position
Tap to select the audio input mode “AUX” or “OPT”
Once connected, you can enjoy boosted sound from your wired audio equipment
1.
2.
3.
4.
5.
6.
Only one of each cable type is included, so you will need to use two different
cable types to connect your two devices to BR-O8 (or supply a second cable if
you want to use two the same). If your connected audio equipment has left &
right channel RCA outputs (colored white and red respectively), you can also use
the included RCA cable to connect
●
- 07 -
Bypass Mode
Note
