PRODUCT DESCRIPTION
1 LCD screen
2 MP3 Control
MODE: USB/SD/BT/FM convertor
Play /Pause
Repeat one / Repeat all / Random
FOL: Long press 5 seconds to enter the folder
option function model (press the previous or
next songs button to choose the folder)
/VOL-: previous song, long press 2second
to low the v o lume,w he n l ong press the volume
will go down to zero.
/VOL+: next song, long press 2 second to
increase the volume, when long press the volume
will go up to 25.
3 SD card input
4 USB input
5 Master Volume control
6 Treble control for high frequencies
7 Bass control for low frequencies
8 MIC input level control
9 Line input level control
10 6.35 mm microphone input
11 (R+L) Iine outputs
12 3.5 mm line input
13 (R+ L) line inputs
14 Clip LED indicator
15 Power LED indicator
16 Speaker out 8 Ohm
17 Fused IEC mains inlet
18 230 V Switch
19 Main power switch
