Before Initial Use
Installation
• Unpack all parts and remove all protective material.
• Connect the unit to any household mains socket after checking the mains voltage and after all other
connections have been made.
• Do not cover any vents and make sure that there is a space of several centimeters around the unit for
ventilation.
Top cover assembly
• Push the metal bracket to the rear.
• Connect the metal bracket to the top cover
• Connect the hinge of the top cover to the main unit
Connection
• Connect the power cord o AC outlet and connect the speaker jack to the speaker terminal located on
the rear side of unit.
• Turn the POWER ON/OFF button (19) clockwise until it clicks dinstinctly.
• Switch the function selector (6) to TUNER. If the LCD display (2) lights up with blue backlight, the power
supply is normal and your system is ready.
Operation
FM Radio
Manual tuning
• Turn the function selector (6) to TUNER and then select desire band (AM, FM or FM-stereo) with the-
BAND/FM-ST selector (10).
• Tune to the desired station by turning the tuning knob (18).
• Use the volume knob (19) to adjust the volume level.
FM & FM-stereo reception
• Set the BAND/FM-ST selector (10) to FM. Programs are received in mono mode. In particular when
stereo signals are weak, it might be preferable to receive the program in mono.
• Set the BAND/FM-ST selector (10) to FM-ST to receive stereo programs. The BAND/FM-ST LED will
light up to indicate FM stereo program is received.
Hints for best reception
AM : The receiver has a built-in AM bar antenna. If AM reception is weak, slight rotation or re-positioning of
the unit will usually improve the reception.
FM : The receiver has a build-in FM wire antenna hanging from the rear cabinet. This wire should be un-
raveled and extended completely for best reception.
