Aunger APT4300 - Page 10

Assemby Instructions for APT4300 – Aunger 4’x 3’ Trailer
10
Your trailer should now look like this:
12. Mount the frontgate. The front gate is the panel with the white reflectors on it.
Put 1 x M8* 15 flange hex bolt and 1 x M8 Lock Washer in each side of the gate at the top
(1). Put 1 x M8*15 flange hex bolt and 1 x M8 Lock Washer in each side at the bottom (2).
Repeat for other side.
Put 2 x M8* 15 flange hex bolt and 2 x M8 Lock Washer in the bottom sill of the gate (3).
1
2
3
