Assemby Instructions for APT4300 – Aunger 4’x 3’ Trailer
11
13. Now all the bolts can be tightened. If you have any problems with lining the panels,
simply undo the the bolts, adjust the panel as necessary and retighten.
Fit the tailgate into the hinges and secure the latches on the sides
14. Mount the mudguard using 2 x M8*20 Hex Bolt, 2 x M8 Spring Washer and 2 x M8 Flat
Washer in each side. Place the flat washer on first with the spring washer on top then
insert bolt. Ensure the long side is to the back.
