Assemby Instructions for APT4300 – Aunger 4’x 3’ Trailer
4
1. Begin by placing the platform upside down as shown. The bolt holes are at the front of
the trailer.
2. Place the axle on the platform as shown and use 2 x M10*30 hex-bolt, 2 x M10 Flat
Washer & 2 x M10 spring washer in each side. Place the flat washer first and put the
spring washer on top and then insert bolt and tighten.
Then fasten all four bolts.
Front of Trailer
Please note: the axle arms are pointing away from the bracket in the front of the trailer.
