Aura Systems AuraGen - Diagram of Typical Auragen Vehicle Installation

M1120221-3, 090630
Owner’s Manual - 4
Typical Engine Mounted AuraGen System
CONTROL AND POWER CABLES ROUTED UNDER VEHICLE TO REAR-MOUNTED ELECTRONIC CONTROL UNIT
REMOTE POWER STRIP (OPTIONAL)
RECEPTACLE OUTLET BOX
AURAGEN MOBILE GENERATOR
THROTTLE CONTROL (LOCATION MAY VARY)
MOUNTING BRACKET (ENGINE AND VEHICLE SPECIFIC)
CONTROL UNIT ON/OFF - STATUS LEDs (USUALLY LOCATED UNDER DASH)
ELECTRONIC CONTROL UNIT
IDLE CONTROL
(LOCATION MAY VARY)
AURAGEN INDUCTION POWER SOURCE
