PWM operating mode
(Pulse-Width Modulation)
By changing the hysteresis settings (chapter “Configuration settings”), you can turn on the PWM
operating mode. In this mode, AURATON Libra cyclically turns on the heating device in order to
minimize temperature fluctuations. AURATON Libra checks temperature rise times and temperature
drop times.
Knowing these values makes AURATON Libra turn on and off the heating device in appropriate cycles
to maintain the temperature to the set value as close as possible.
Temperature1.
Time2.
Set temperature3.
Room temperature4.
IMPORTANT:
AURATON Libra can turn on the heating device despite the fact that the temperature in
the room is higher than the set temperature in the PWM mode. This is caused by the
PWM algorithm aiming at maintaining the set temperature and anticipating the
