Auriol 353517 2007 - Parts Description

9 GB
Parts description
Figure A+B
Display
1
Date panel
2
Outdoor temperature
panel
3
Indoor temperature panel
4
USB connection panel
5
Time panel
Weather station
6
MODE button
7
+ / MEM button
8
– / CH button
9
ALARM button
10
NAP button
11
SNOOZE / LIGHT button
12
RESET button
13
Battery compartment
cover
14
Mains adapter
15
Mains adapter plug
16
Connector socket for
mains adapter
17
Battery compartment
18
USB socket (Type A)
Figure C
Outdoor sensor
19
Outdoor sensor display
20
Control LED
21
Hanger
22
°C / °F selector
23
TX button
24
Channel selector switch
25
Battery compartment
26
Dowel (Ø 6 mm)
27
Screw (Ø 3 mm)
28
Battery compartment
cover
