Aussie Fit V-450 - STEP 1: Attach the Front Support (Front Stabilizer); Front Support Attachment

ASSEMBLY
STEP 1: Attach the Front Support (Front Stabilizer)
NOTE: To make attaching the support easier place a large Styrofoam
block under the machine.
(A) Attach the front support to the base frame with the wheels facing
outward.
(B) Align the 2 bolt holes in the front support with the bolt holes in the
main frame.
(C) Secure the front support to the main frame by using 2 x #19 bolts
inserted through the bottom, 2 x # 65 washers 2 x 20 lock nuts and 2
x #21 nut covers
(D) Tighten all bolts now.
#19
2
#65
2
#20
2
#21
2
