Autel MaxiTPMS TS601 Instruction Manual

7
7) CD -- Includes user’s manual, PC Suit, etc.
8) SD Card -- Used to store data.
3.4 Icons
1) “ ” – Indicates battery charging.
2) “
” -- Indicates there is data stored in the tool.
3) “
” -- Indicates battery volume.
4) “
” -- Indicates USB communication with the computer is
established.
5) “
” -- Indicates magnet is required to activate TPMS sensor.
6) “ ”-- Indicates deflation is required to activate TPMS sensor.
7) “
” -- Indicates test mode One Wheel is selected.
8) “
” -- Indicates test mode ALL Wheels is selected.
9) “
” -- Indicates the TPMS tool is sending signals to the tire
sensor for activation and test.
10) “
” -- Indicates tool communication with the vehicle’s OBDII
DLC is established.
3.5 Keyboard
No solvents such as alcohol are allowed to clean the keypad or
display. Use a mild nonabrasive detergent and a soft cotton cloth. Do
not soak the keypad as the keypad is not waterproof.
3.6 Battery Charging
The TPMS tool has a 3.7V built-in lithium-ion polymer rechargeable
battery. There are two means of battery charging:
