8-3
TECHNICAL SPECIFICATION
WEIGHT AND DIMENSION DATA
WEIGHT DATA TABLE
GLOUCESTER 2.1 TDCi 2.1 TDCi
MANUAL AUTOMATIC
Vehicle Designation 315 CDi 315 CDi
MTPLM 3880 3880
Mass in Running Order 3363 3395
Mass of the User Payload 517 485
Conventional Load @ 75kg per person) 75 75
Designated Passenger Seats
(excluding driver) 1 1
Essential Habitation Equipment 161 161
Personal Effects (standard minimum figure) 93 93
Remainder for Personal Effects / Options /
Accessories 188 156
Optional Roof Rack + Ladder 10 10
Optional Omni Vent 2 2
Optional Corner Steadies std std
Gross Train Mass 5880 5880
MBTM 2000 2000
Axle Weights
Front, in Running Order 1562 1594
Rear, in Running Order 1712 1712
MTPLM Front 1800 1800
MTPLM Rear 2430 2430
To Next Page
