9
4) Daytime and Nighttime mode
Daytime mode
The camera automatically switches to daytime mode in daytime or high light conditions, and the screen displays color images.
Nighttime mode
The camera automatically switches to nighttime mode in nighttime or low light conditions and the infrared lights turn on to fill light, then the
screen displays black and white images.
Note: When the light conditions suddenly change from dark to bright, the black and white image will be switched to the color image after 5
seconds. To avoid the image constantly jumps between black and white image or color image when driving at night and being illuminated by
the lights behind the car.
5) Standby mode
When the product works normally, press and hold OK for 3 seconds, the monitor turns off and enters into standby mode. It exits standby mode
after pressing OK again. Or when the Cam1 is triggered on the standby mode, the monitor turns on and shows the image again.
Monitor
Diagonal screen size
Power supply
Current consumption
Camera
View angle
Current consumption
Operating frequency
7”
DC 12-24V
Max 300mA (@12V)
Diagonal 135°±5°
Max 650mA (@12V)
2.4GHz ISM
Screen brightness
Transmission frame rate
Operating temperature
Power supply
Minimum illumination
Operating temperature
500 cd/m² (Typ.)
25 FPS
-20°C~65°C
DC 12-24V
0 Lux (Fully automatic night switch infrared light fill light）
-20°C ~65°C
Technical Specifications
