AutoAnchor 710-6 - Technical Specifications

3
TECHNICAL SPECIFICATIONS
Parameter AA710 Remote Console AA702 Base Station
Power Supply 2 x AA 1.5V Batteries 12V/24V DC
Maximum Voltage 30V DC
Current Consumption N/A 50mA
Output Maximum
Current Draw
N/A 12V DC: 3.5A
24V DC: 3.5A
The system has internal current
limiting and thermal shutdown.
Output Minimum
Current Draw
N/A 12V DC: 10mA
24V DC: 20mA
IP Rating IP67 IP67
Operating Temperature
Range
23
o
F to 140
o
F (-5
o
C to 60
o
C) 23
o
F to 140
o
F (-5
o
C to 60
o
C)
Wireless Transmission 2.4GHz ISM Band, IEEE 802.15.4 Compliant, 64 Bit Unique ID
Wireless Range Typical Minimum 10m (30ft). Range depends on installation.
Outputs 6
System Supports Up to 3 base stations and 3 consoles
Rode - Chain Only Stainless or galvanised steel.
Rode - Rope and Chain Must have a minimum of 10ft (3m) of chain. Chain must be
galvanised steel. Rope should be a good quality, nylon anchor
rope. Type 66 or equivalent.
DC windlasses require a dual direction solenoid
