Mazda P-D Testing
After connecting the testing device, the main menu will appear on the display:
Select the P-D function and conrm by pressing the OK button.
During the test, after starting the alternator drive, the actual voltage value should correspond to the
required value. Some discrepancies between the voltage values are acceptable. What is important is the
appropriate reaction of the alternator – increasing or decreasing the output voltage according to the
required voltage.
Selected function
DFM value
Required voltage
Actual voltage
