Automate AM2 - standard transmitter configuration

4
© 2007 directed electronics, inc.
ssttaannddaarrdd ttrraannssmmiitttteerr ccoonnffiigguurraattiioonn
controls the Lock/
AArrmm
function.
controls the Unlock/
DDiissaarrmm
function.
controls
AAuuddiibbllee MMooddee
and an
AAuuxxiilliiaarryy OOuuttppuutt
.
controls the
PPaanniicc
function.
and pressed together control an
AAuuxxiilliiaarryy OOuuttppuutt
.
wwhhaatt iiss iinncclluuddeedd
➤ The control module
➤ SHF Plus Receiver
➤ A pair of four-button transmitters
➤ A combo push button LED switch
➤ Your warranty registration
