STRATUS TA20 Series Industrial Air Conditioners User Manual
1st Edition RevA.
Features
• Condensate Removal System
• High Condenser Refrigerant Temperature Control
• Low Refrigerant Pressure Cut-out Switch
• Digital Temperature Control Thermostat troubleshooting
diagnostics
• Anti short-cycle Time Delay and Bypass Time Delay
• Condenser Fan Cut-in Control Pressure Switch
• Powder coated to prevent rust (NEMA/UL Type 12 and 4)
• Material: NEMA/UL Type 12, Type 4: 16-gauge cold
rolled steel chassis and shroud
• NEMA/UL Type 4x: 304 stainless steel chassis and shroud
• Chassis and shroud seal system ensures closed loop air
circulation
• Condenser inlet air filter
• Thermal expansion valve provides high performance over
wide temperature range
• Internally insulated to minimize case heat loss
• Schrader valves on low AND high pressure service ports
• High efficiency performance = high BTU per KWH for
minimal electricity cost
• Auxillary alarm contacts as a standard
NEMA Type 12 Unit Specifications
Model
BTU/H @
Max. Ambient
Temperature
Standard Max.
Ambient Temperature
Volts/Hertz
Running
Amps
Unit
Weight
(lb)
Refrigerant
Type
Refrigerant
Amt. (oz)
Typical
Frame Size
TA20-010-16-12
1000
125°F (51.67°C)
115/60 2.70 31
R134a
6.00
TA20-0
TA20-010-48D-12
48VDC 3.50 30 6.00
TA20-020-16-12
2000
115/60 4.10 42 12.00
TA20-1
TA20-020-26-12
230/60 2.00 45 12.00
Unit Specifications
Voltage variation no greater than ± 10% from nameplate rating and Frequency variation no greater than ± 3Hz from nameplate
rating.
