Autool BT30 - Structure Diagram; Product Structure; Technical Parameters

4
Operating Voltage
Operating Current
Operating Temperature
10-14V
＜7A
-20~60°C
Technical Parameters
PRODUCT STRUCTURE
Structure Diagram
A
Power Clamp
C
Voltage Display
E
Current Display
B
Built-in 3A Fuse
D
OBD Interface
F
Power Switch
A
D
C
E
F
B
Over-current protection (includes a built-in 3A fuse).
Simultaneous display of voltage and current.
●
●
