Autotek ATA800.2 - Page 2

INDEXPAGE
General Installation Procedure..........................................................................................................................................................................................1
Amplifier Feature Descriptions...........................................................................................................................................................................................2
2-CHANNEL AMPLIFIER APPLICATIONS......................................................................................................................................................................3
4-CHANNEL AMPLIFIER APPLICATIONS...................................................................................................................................................................4-5
1 CHANNEL AMPLIFIER APPLICATIONS.......................................................................................................................................................................6
Features and Specifications...............................................................................................................................................................................................7
Setting Up SystemsAfter Installation For Best Performance...............................................................................................................................................8
Troubleshooting and Diagnostics.......................................................................................................................................................................................9
Product Warranty.............................................................................................................................................................................................................10
Full range stereo / mono
4, 3 and 2 channel operation / front/rear high pass using a 2 channel model for mono sub bass
Basic mono amplifier application
ATA SERIES AMPLIFIERS
Congratulationsonyourpurchaseandthankyouforsupporting AUTOTEK!The ATA Seriesproductshavebeen
designedtoaveryhighlevelofperformance,withfeaturesunavailableinsimilarlypricedamplifiers.Theseamplifiers
havevariablecrossoversbuiltin,withaddedtouchessuchassubsonicfilter,bassequalizationandaremoteLevel
controlmodule(somemodels)thatallowssubwooferLevelcontrolfromthedriversseat.Themultichannelmodels
havekeptyourfactoryheadunitandexistingcontrolsinmindbyofferinghighlevelinputswhichallowforyourOEM
radiotoremaininplace.Pleasereadthroughthismanualcompletelyaswehavecompiledaguidethatwillkeepyou
ontheroadandenjoyingyourmusicforyearstocome.
ThecaraudioprofessionalsatMaxxsonicsrecommendthatyouonlyuseoneoftheMAXXLINKamplifierinstallation
kitstoinstallthisamplifier.TheMAXXLINKamplifierinstallationkitsaredesignedtodeliverproperpowerandfusing
totheamplifierfromthevehicleselectricalsystem. Additionally,thekitincludessignalcables(RCA's)thatare
designedtorejectnoiseandimprovesignalqualityfromthesourceunittothepre-amplifiersection.Thisampis
goingtosoundunbelievable.
UseofMAXXLINKproductsensuresthatyouramplifierwilldelivermaximumperformanceforyearstocome.
Maxxsonicsissoconfidentinthisamplifier,installedproperlywithaqualifyingMAXXLINKampkit,youcanaddupto
12monthsofadditionalwarrantycoveragetothisamplifier!Formoreinformation,pleasecheckout
.CheckoutalltheMAXXLINKproductsforyourinstallationat
TREADLOUDLY!
MAXXLINKAudio.com/Warranty MAXXLINKAudio.com
Checkoutourvideosof newproducts,
eventsandtechnicaltutorialsat
www.youtube.com/maxxsonicsusainc
