AUX ARV SERIES INDOOR UNIT – DC&AC TYPE Technical&Service Manual
3
Part1 General Information
1. Nomenclatures
ARV T CA - H 028 / 4 R1 A
Design Series Code
Refrigerant Type:
R1:R410A R22 Omitted
Power Supply：
2: 220-240V~/1Ph/ 60Hz 4: 220-240V~/1Ph/50Hz
5: 380-415V~/3Ph/50Hz 6: 380-415V~/3Ph/60Hz
9:208-230V~/3Ph/60Hz
N:220-240V~/1Ph/50/60Hz
S: 380-415V~/3Ph/50/60Hz
Cooling Capacity (×100W)
H: Cooling & Heating C: Cooling Only
Indoor Unit Type：
C1：One-way Cassette C2：Two-way Cassette
CA：Four-way Cassette CF：Ceiling&Floor
SD：Slim Duct MD：Mid ESP Duct
HD：High ESP Duct WM：Wall Mounted
FA：Fresh Air Processer
Climate Class:
T: T3 Type
AUX Refrigerant Variable AC
