ONLY USE CORTRAK* 2 IF TRAINED
SET UP
Positioning and Setup
Make Connections and Inspect
Turn On and Login
Place Front Foot of Receiver on Xiphoid Process
Position patient
per institution
protocol.
Receiver to
Monitor
Palpate lower sternum,
follow to Xiphoid.
Secure Receiver with tape
(directly on skin) or with weight.
Place front foot of Receiver on Xiphoid, align vertically and parallel with
spine. To level for patient, place a towel under the Receiver.
Turn Monitor on.
Press and hold
for approximately
5 seconds until it
remains green to
power on.
Enter your login &
password.
Monitor position
Receiver Unit and
Monitor should be at
least 2’ apart.
Interconnect Cable
to Monitor
Select “New
Placement”.
Enter patient
information
(first and last
name, ID #).
1
2
3
4
To Next Page
