Avantgarde LBWC-42SD - Components and Parts

COMPONENTS AND PARTS
1) Temperature Control and Display (Left
Zone)
2) Circulation Fan
3) Interior Light
4) Cabinet
5) Temperature Control and Display (Right Zone)
6) Drip Pan
7) Sculptured Vinyl Shelf (Wine Storage)
8) Flat Chrome Shelf ( Beverage Storage)
SPECIFICATIONS - Model LBWC-42SD
Product Description 24” Stainless Steel Built-In Wine & Beverage Center
Model No. LBWC-42SD
Width Height Depth Unit Dimensions
( inches )
23 1/2” 34” 23 1/4”
Net Weight ( lbs) 104 lbs
Built-in requirements
Width Height Depth
Width, Depth, Height
24” 34 ½” 24”
Note:
The control panels (Item no.
1 & 5) are on the front of the unit.
13
