Jumper Clamp Indicator Instruction
Input low
voltage
protection
13.0V±0.3V
The red light is always on, the green light is
off, and the buzzer does not sound.
Input high
voltage
protection
18.0V±0.5V
The red light is always on, the green light is
off, and the buzzer does not sound.
Work instruction
Support
When working normally,the green light is
always on, the red light is off, and the buzzer
beeps once.
Reverse
connection
protection
Support
The red/black clip of the wire clip is
reversely connected to the car battery
(battery voltage ≥0.8V), the red light is
always on, the green light is off, and the
buzzer sounds at short intervals.
Start timeout
protection
90S±10%
The red light is always on, the green light is
always on, and the buzzer does not sound.
Short circuit
protection
Support
When the red and black clips are
short-circuited, no sparks, no damage, the
red light is always on, the green light is off,
the buzzer 1 long and 2 short beeps.
Connect to the
high voltage
alarm
Support
The clip is mistakenly connected to battery
that is >16V, the red light is always on, the
green light is off, and the buzzer sounds
slowly and shortly.
Automatic
anti-virtual
electricity
function
Support
When the car battery voltage is higher than
the Starter battery voltage, the output is
automatically turned off and the green light
is on,at this time, it can be ignited normally.
If the car battery voltage drops and is lower
than the starter battery voltage during the
ignition process, the smart clip will
automatically turn on the output to complete
the startup process.
Item
Technical
parameters
Instruction
07
