Testing the complete configuration
140 Installing and Connecting the MDF and Telephones
Figure 63: Sample test results for Expansion Interface Board 2A01
Testing time division multiplexing bus for each port network
To check each TDM bus for each port network (PN) in the configuration.
1. Type test tdm port-network 1 and press Enter.
2. Verify a Test Results screen similar to Figure 64: Sample test results for TDM bus port
network 1 on page 140 appears.
3. If result is FAIL for any test, check the connectors of the TDM bus cables in PN 2.
4. Repeat these steps for each PN to check the TDM bus cables.
Figure 64: Sample test results for TDM bus port network 1
TEST RESULTS
Port Maintenance Name Alt. Name Test No. Result Error Code
02A01 EXP-INTF 237 PASS
02A01 EXP-INTF 238 PASS
02A01 EXP-INTF 240 PASS
02A01 EXP-INTF 241 PASS
02A01 EXP-INTF 244 PASS
02A01 EXP-INTF 316 PASS
test tdm port-network 1
TEST RESULTS
Port Maintenance Name Alt. Name Test No. Result Error Code
PN 01A TDM-BUS 294 PASS
PN 01A TDM-BUS 296 PASS
PN 01A TDM-BUS 297 ABORT 1005
PN 01B TDM-BUS 294 PASS
PN 01B TDM-BUS 296 ABORT 1005
PN 01B TDM-BUS 297 PASS
