Model 6600R Analog Audio DA
Input:
Number 2, Differential, Channel A and Channel B,
(Channel A only used for mono).
Impedance > 30k Ω, balanced, 12k Ω unbalanced
Maximum Level + 30 dBu (66 Ω), + 24dBm (600 Ω)
Common Mode Range ± 20V
Common Mode Rejection
(CMRR) > 90 dB @ 60Hz, > 60 dB @ 20 kHz
Remote Gain:
Control Type Local/Remote, switch selectable
DC Control Range ± 20 dB
Outputs:
Channels 1 (mono) or 2 (stereo)
Outputs per channel 6 (mono) or 3 (stereo)
Output Impedance 66 Ω or 600 Ω balanced
Output Isolation > 70 dB, 20 Hz to 20 kHz
Maximum Level + 30dBu (66 W), + 24dBm (600 W)
Performance:
Gain Range ± 20 dB
Frequency Response < ±0.05 dB 20 Hz to 20 kHz, relative to 1 kHz,
any level up to + 30dBu (66 Ω), +24dBm (600 Ω)
Total Harmonic Distortion < 0.05%, 20 Hz to 20 kHz @
+ 30dBu (66Ω), +24dBm (600Ω)
S/N Ratio > 80dB @ unity gain 20Hz to 20KHz,
relative to +8 dBu, unweighted
Intermodulation Distortion < 0.02%. SMPTE @ +18dBu (66Ω)
Isolation Between Modules > 100dB, 20 Hz to 20k Hz
Performance Temperature 5 - 40° C
Maximum Operating
Temperature Range 0 - 50° C
Power Dissipation 2.5 W
Due to ongoing product development, all specifications subject to change.
6600-12
Model 6600 Analog Audio DAs and Frame
