SPECIFICATIONS
Model 6600 Analog Audio DA
Input:
Number 2, Differential, Channel A and Channel B,
(Channel A only used for mono).
Impedance > 30k Ω, balanced, 12k Ω unbalanced
Maximum Level + 30dBu (66 Ω), + 24dBm (600 Ω)
Common Mode Range ± 20V
Common Mode Rejection
(CMRR) > 90dB @ 60 Hz, > 60 dB @ 20 kHz
Outputs:
Channels 1 (mono) or 2 (stereo)
Outputs Per Channel 8 (mono) or 4 (stereo)
Output Impedance 66 Ω or 600 Ω balanced
Output Isolation > 70 dB, 20 Hz to 20 kHz
Maximum Level + 30dBu (66 Ω), +24dBu (600 Ω)
Performance:
Gain Range - 6 dB to + 33 dB
(± 6 dB on pot, 0, +9, +18, +27 dB on jumpers)
Frequency Response <± 0.05 dB 20 Hz to 20 kHz, relative
to 1KHz, up to +30dBu (66Ω), +24dBm (600Ω)
Total Harmonic Distortion < 0.05%, 20Hz to 20kHz @
+ 30 dBu (66 W), +24 dBm (600 Ω)
S/N Ratio > 100dB @ unity gain 20 Hz to 20k Hz,
relative to +8dBu, unweighted
Intermodulation Distortion < 0.02%. SMPTE @ +18dBu (66Ω)
Isolation between modules > 100dB, 20 Hz to 20k Hz
Performance Temperature 5- 40° C
Maximum Operating
Temperature Range 0 - 50° C
Power Dissipation < 2W
Due to ongoing product development, all specifications subject to change.
