Avision AV332IL - Page 99

User’s Manual
4-72
 EAN-8
 GS1 DataBar
 Industrial 2 of 5
 Intelligent Mail
 Interleaved 2 of 5
 Inverted 2 of 5
 IATA 2 of 5
 Matrix 2 of 5
 PostNet
 Royal Post 4-State
 UPC-A
 UPC-E
Note:
 Recommended resolution: 200~600 dpi for regular
barcode, 300~600 dpi for QR code
 Skewed barcodes may not be recognized correctly.
 Using the same sheet repeatedly may decrease the
recognition accuracy due to accumulated dirt on the sheets.
If the sheet is not recognized correctly or gets smudged,
replace it with a new sheet.
Barcode Zone:
Specify the barcode zone to be detected.
Select 「All」 to checks the whole document and detects
barcodes. Or you may speed up the process by specifying a
detection area since only the specified area is checked.
Choice: All, Top, Bottom, Left, Right, Bottom Right,
Bottom Left, Top Right, Top Left
