Product Introduction
4
Product Introduction
Front View
Rear View
TV/AV:
Display the input source menu.
MENU:
Display/exit the OSD menu.
CH+/-:
Scan through channels.
VOL+/-:
Adjust the volume.
POWER:
Turn on/standby the TV set.
Remote Control window(keep clear)LED indicator
(IR) Infrared Receiver: Receives IR signals from the remote control.
(Power on/Standby) LED indicator: Press POWER to turn on and off.
The effective receiving range for the signal is 5-8 metres from the front of the remote
control window, and 30
0
to the left or right side and 20
0
above or below the control
window.
Indicator on(Red) Standby mode
Indicator on(Green) Power on mode
TV/AV MENU CH+ CH- VOL+ VOL- POWER
TV/AV MENU CH+ CH- VOL+ VOL- POWER
Connections--See next page
Connections--See next page
AC POWER IN
