Avonic CM7 IP Series - Video

Audio Configure
Sample Rate {"SetEnv":{"Audio":{"nSampleRate":32000}}} nSampleRate (Only supporting
these sample rates and gy11a
can only be 8000.)
16000
32000
44100
48000
Sample Bits {"SetEnv":{"Audio":{"nSampleBits":16}}} nSampleBits 16
Bit Rate {"SetEnv":{"Audio":{"nBitRate":96}}} nBitRate 32
48
64
96
128
Channel {"SetEnv":{"Audio":{"nChannel":2}}} nChannel 1: Mono
2: Stereo
Input Volume {"SetEnv":{"Audio":{"nInpVolume":5}}} nInpVolume (range 1 to 10) Exp:[1, 10]
Video
Video encoder
Video Encode
Get video encode parameters
Code {"GetEnv":{"VideoEncode":{"nChannel":-1}}}
Set video encode parameters
Code {"SetEnv":{"VideoEncode":[{"stSlave":{"byIFrameMinQP":20,"byImageQuality":1,
"szStreamName":"live/av1","dwVideoCodecMask":160,"emBitRateCtrl":0, "byImageSizeList":
[26,7,9,27,4,5],"dwMaxBitRate":40960,"nFrameRate":25,"nMaxFrameRate":30,
"emVideoCodec":5,"nIFrameInterval":75,"emImageSize":27,"nBitRate":512,"byProfile":2},
"stMaster":{"byIFrameMinQP":20,"byImageQuality":0,"szStreamName":"live/av0",
"dwVideoCodecMask":160,"emBitRateCtrl":0,"byImageSizeList":[5,4,9],"dwMaxBitRate":40960,
"nFrameRate":25,"nMaxFrameRate":60,"emVideoCodec":5,"nIFrameInterval":75,"emImageSize":5,
"nBitRate":4096,"byProfile":2},"nChannel":0}]}}
Video encode settings
Video Encode Settings
Function Code Command Setting
Compressed Format {"SetEnv":{"VideoEncode":[{"stMaster":
{"emVideoCodec":5},"nChannel":0}]}}
emVideoCodec 5: H.264
7: H.265 (BP profile only)
Profile {"SetEnv":{"VideoEncode":[{"stMaster":
{"byProfile":0},"nChannel":0}]}}
byProfile 0: BP
1: MP
2: HP
{"GetEnv":{"VideoEncode": {"nChannel":-1}}} and
receive its returning value. Compared to webpage
and this, you can know the different value meaning
different image size.
byImageSizeList (Lists
all imagesize, different
products have different
image size)
Image Size {"SetEnv":{"VideoEncode":[{"stMaster":
{"emImageSize":4},"nChannel":0}]}}
emImageSize 5: 1920*1080
4: 1280*720
9: 640*480
27: 320*180
26: 640*360
Rate Control {"SetEnv":{"VideoEncode":[{"stMaster":
{"emBitRateCtrl":1},"nChannel":0}]}}
emBitRateCtrl 0: CBR
1: VBR
User Manual | www.avonic.com 11
