Avonic CM7 IP Series - Page 15

Camera Settings
Exposure: AEE
Flicker {"SetEnv":{"VideoParam":[{"stExp":
{"antiflicker":0},"nChannel":0}]}}
Antiflicker 0:
1:
2:
OFF
50HZ
60HZ
G.Limit {"SetEnv":{"VideoParam":[{"stExp":
{"gainLimit":5},"nChannel":0}]}}
gainLimit [0, 15]
Iris {"SetEnv":{"VideoParam":[{"stExp":{"stIris":
{"nIris":12}},"nChannel":0}]}}
nIris [0, 12]
DRC {"SetEnv":{"VideoParam":[{"stExp":
{"drc":6},"nChannel":0}]}}
drc [0, 8]
Exposure: Bright
Bright {"SetEnv":{"VideoParam":[{"stExp":
{"bright":0},"nChannel":0}]}}
bright [0, 23]
Flicker, G.Limit, DRC You can find the same configure at AAE
Color and Image
Camera Settings
Color
Function Code Command Setting
WB
Mode
{"SetEnv":{"VideoParam":
[{"stColor":{"stWbMode":
{"emWbMode":0}},"nChannel":0}]}}
emWbMode 0:
1:
7:
2:
8:
4:
9:
10:
6:
11:
5:
3:
Auto
3000K
3500K
4000K
4500K
5000K
5500K
6000K
6500K
7000K
Manual
OnePush
RG
Tuning
{"SetEnv":{"VideoParam":
[{"stColor":
{"rgaintuning":0},"nChannel":0}]}}
rgaintuning [0, 20]
BG
Tuning
{"SetEnv":{"VideoParam":
[{"stColor":
{"bgaintuning":20},"nChannel":0}]}}
bgaintuning [0, 20]
Saturation {"SetEnv":{"VideoParam":
[{"stColor":
{"saturation":0},"nChannel":0}]}}
saturation [0, 14]
Hue {"SetEnv":{"VideoParam":
[{"stColor":
{"hue":14},"nChannel":0}]}}
hue [0, 14]
AWB
Sensitivity
{"SetEnv":{"VideoParam":
[{"stColor":
{"awbsens":0},"nChannel":0}]}}
awbsens 0:
1:
2:
Low
Middle
High
User Manual | www.avonic.com 15
