MAINTENANCE
!
let brake fluids, gasoline, products, penetrating oils, etc., come in
contact with plastic parts. Chemicals can damage, weaken
or destroy plastic which can result
in serious personal injury.
Keep the tool clean using a soft damp (not wet) cloth.
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean cloths to
remove dirt, dust, oil, grease, etc.
To maintain the best performance of your rechargeable battery, protect it from overheating, both
from overcharging and during storage. Charge the battery for 7 hours before the first time use.
9
PARTS LIST
NO DESCRIPTION
1
2
3
4
5
6
7
9
10
11
Left housing
Absorber
Digital gauge
Air pump assembly
Microswitch
Trigger
Spring
8
Motor
Torsional spring
Fan
Self-locking switch
NO DESCRIPTION
12
13
15
16
17
18
19
20
21
Right housing
Screw
14
Screw
LED cover
Red wire 1
LED light
Red wire 2
Black wire
Battery clip assembly
Battery Pack
