Installation Instr. : E92DGA
Autor:
AWRON GmbH
Version: V1.1
Datum: 22.02.2016
Seite: 11
Cable installation on passenger footwell side
Contact must be switched off or put the key in the ignition lock mandatory!
Screwdriver TORX T20
Remove the screws
marked in the picture of
the footwall cover. For
this operation use
Thorax T20
1
Power distribution
2
Junction box control unit
Blue
X14271
Black
X14272
