Awron E92DGA M3 User Manual

Installation Instr. : E9xDGA
Autor:
AWRON GmbH
Version: V1.1
Datum: 28.04.2015
Seite: 15
Insert two pins of the vehicle wiring harness into white connector housing. Orientate and pay attention on
the color of the AWRON wire and unplag pin 1 and pin 2 from AWRON harness into blue connector on
the position like picture showed.
Cable installation on passenger footwell side
Contact must be switched off or put the key in the ignition lock mandatory!
Connect white connector from vehicle harness to the white connector from AWRON harness
1
2
CONNECT
