12
Range Accuracy Resolution
1Hz
±(0.5% + 10 d)
0.001Hz
10Hz 0.01Hz
100Hz 0.1Hz
1kHz 1Hz
10kHz 10Hz
100kHz 100Hz
1MHz 1kHz
30MHz 10kHz
0.1 – 99.9% For your reference 0.1V
Input Sensitivity: > 0.7V RMS
Overload Protection: 250V DC or AC Peak Value
2.2.9. Temperature (°C)
1. Rotate function switch to (°C) gear
2. Insert the cathode (black pin) of cold end (free end) of thermocouple into “COM” jack and anode
into terminal. Then put the working end (temperature measurement end) of thermocouple
on the surface or inside the object to be tested. Then you can read temperature from the screen,
and the data is in Centigrade.
Caution:
1. When the input terminal is open-circuit, it will display the normal temperature.
2. Don’t change the temperature probe at random, or the value accuracy could not be guaranteed.
3. Don’t measure voltage at temperature range.
Range Accuracy Resolution
(-20 ~ 1000)°C
<400°C ± (1.0% + 5 d)
≥400°C ± (1.5% + 15 d)
1°C
Sensor: K Type Thermocouple (Nickel-chromium-nickel silicon) (banana plug).
CAUTION: DO NOT INPUT VOLTAGE AT THIS RANGE!
