Hardwareoverview
Hardwareoverview
Forspecicationsofthehardwarecomponents,seeTechnicalspecicationsonpage37.
1
Networkconnector
2
Microphoneswitch
3
SDmemorycardslot
4
Controlbutton
ConnectorsandButtons
Networkconnector
NO NO
NO
TICE TICE
TICE
Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingtheproducttothenetworkshall
beintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledinaccordancewiththemanufacturer’s
instructions.Forinformationaboutregulatoryrequirements,seeElectromagneticCompatibility(EMC)onpage2.
ControlButton
Forlocationofthecontrolbutton,seeHardwareoverviewonpage6.
Thecontrolbuttonisusedfor:
•SendingoutatesttonethatcalibratestheAutoSpeakerTest.Pressandreleasethecontrolbutton.
•Resettingtheproducttofactorydefaultsettings.Seepage34.
•ConnectingtoanAXISVideoHostingSystemservice.Seepage29.Toconnect,pressandholdthebuttonforabout3
secondsuntiltheStatusLEDashesgreen.
