If your Dyno electronics are connected, you should see the Hardware showing Connected.
Run Start Speed?
Run Start RPM?
Correction Factor?
Setting up the Inertia Disks
The Axis Dyno inertia can be adjusted to reflect the total weight being accelerated.
Total weight = vehicle + fluids + cargo + passengers
Disk Weight Chart
Note: Use spacers with 5 disks or less
18 in dia drum, 80t driver, 28t driven, and 17 in dia disks
When changing inertia discs, it is very important that they are aligned correctly in order to
maintain balance. The punch mark on the ½” stud needs to be aligned with the punch mark on
each disk and must be oriented vertically before tightening.
15
