Axis F44 - Connection Diagrams and Pinouts; I;O, Power, and Audio Connector Diagrams

AXISF44MainUnit
TechnicalSpecifications
Digitalinput–Connecttopin1toactivate,orleaveoating
(unconnected)todeactivate.
0tomax30VDC Congurable
(InputorOutput)
3–6
Digitaloutput–Connectedtopin1whenactivated,oating
(unconnected)whendeactivated.Ifusedwithaninductive
load,e.g.arelay,adiodemustbeconnectedinparallelwith
theload,forprotectionagainstvoltagetransients.
0tomax30VDC,opendrain,
100mA
ConnectionDiagrams
I/OConnector
1
2
3
A
B
D
S
G
1
0VDC(-)
2
DCoutput12V,max50mA
3
Example:pushbutton
A
I/Oconguredasinput
B
I/Oconguredasoutput
PowerConnector
2-pinterminalblockforDCpowerinput.UseaSafetyExtraLowVoltage(SELV)compliant
limitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Woraratedoutput
currentlimitedto≤5A.
AudioConnector
3.5mmaudioconnectors
(stereo)
123
63
