What’s Included
3
Quantity Item Part
508334
1 No Base 1
1 No Tube Support Bar 2
2 No Upright Supports 3
1 No Tube Handle 4
1 No Filter Dust Bag 5
1 No Filter Assembly 6
2 No Foam Seal Bands 7
2 No Filter and Bag Retaining Belts 8
1 No Shaker Paddle Operating Handle 9
2 No Wheels 10
2 No Castor Wheels 11
Extractor Fixings 12
1 No 5mm Hex Key a
1 No 10-12mm Spanner b
2 No 1/2" Lock Nut c
2 No 1/2" Nuts d
2 No Thin Washers e
2 No Nylon Washers f
2 No Medium Washers g
2 No Large Washers h
8 No 5/16" UNC Domed Cap head Bolts i
12 No 5/16" UNC Hex Bolts (Short) j
2 No 5/16" UNC Hex Bolts (Long) k
2 No 1/2" Large Hex Bolts l
1 No Extractor Assembly 13
Quantity Item Part
508336
1 No Base 14
1 No Tube Handle 15
1 No Upright Support 16
1 No Tube Support Bar 17
1 No Inlet Manifold 18
1 No Filter Dust Bag 19
1 No Filter Bag Retaining Belt 20
2 No Wheels 21
2 No Castor Wheels 22
1 No Shaker Paddle Operating Handle 23
1 No Filter Retaining Belt 24
2 No Foam Seal Bands 25
1 No Filter Assembly 26
Extractor Fixings 27
1 No 5mm Hex Key a
1 No 10-12mm Spanner b
2 No 1/2” Lock Nut c
2 No Nylon Washers d
2 No Thin Washers e
2 No Medium Washers f
2 No Large Washers g
1 No Small Phillips Screw No: 10 ANC h
20 No 5/16" UNC Hex Bolts (Short) i
2 No 5/16” UNC Hex Bolts (Long) j
2 No 1/2” Large Hex Bolts k
1 No Extractor Assembly 28
Model Number CT-90H Model Number CT-90HB
Please read the Instruction Manual prior to using your new machine. As well as the operating procedures for
your new machine, there are numerous hints and tips to help you to use the machine safely and to maintain
its efficiency and prolong its life. There is also a detailed description of the parts of your Extractor, which
will enable you to become familiar with terminology we will use in this manual. Keep this Instruction Manual
readily accessible for any others who may also be required to use the machine.
