Exploded Diagram/Parts List
41
Diagram/List A
NO
DESCRIPTION
A-1
Sliding panel set
A-2
Hex head screw M10x55
A-3
Washer 10mm
A-4
Hex nut M10
A-5
Washer 6mm
A-6
Lock nut M6
A-7
Check door
A-8
Knurled knob M6x20
A-9
Safe guard
A-10
Pan head screw M6x30
A-11
Spacer
A-12
End cap
A-14
"L"plate
A-15
Pan head screw M5x10
A-16
Limit switch QKS8
A-17
Key switch
A-18
Limit switch Qks7
A-19
Pan head screw M4x30
A-20
Hex nut M4
A-21
Pan head screw M4x10
A-22
Plate
A-23
Box stand
A-24
Pan head screw M6*12
A-25
Washer 6mm
A-26
Dust port
A-27
Strain relief
A-28
Switch box
A-29
Sealer
A-30
Cover,switch box
A-31
Washer 4mm
A-32
Pan head screw M4x12
A-33
Rubber seal
A-34
Main switch
A-35
taping screw ST4.2x20
A-36
Pan head screw M5x16
A-37
Washer 5mm
A-38
Hex nut M5
A-39
Kee touch plate
A-40
Push stick
A-41
Holder,push stick
A-42
Contactor CJX2 1810
