Diagram/List C
Continues Over....
NO. DESCRIPTION
C-1 Frame-blade
C-2 Shaft-main blade
C-3 Main shaft
C-4 Shaft housing-scoring
blade
C-5 Shaft-scoring blade
C-6 Pulley-scoring blade
C-7 Gear house
C-8 Rotating support
C-9 Main blade
C-10 Pointer
C-11 Slide piece
C-12 Scoring blade
C-13 Bearing house
C-14 Shaft
C-15 Stop,scoring blade
C-17 Main shaft+pulley
C-18 Rod
C-19 Shaft rod
C-20 Frame segement
C-21 Pulley
C-22 Hex nut
C-23 Pulley-motor
C-24 Motor base
C-25 Shaft
C-26 Pulley
C-27 Tension shaft
C-28 Sunken head screw M8x20
C-29 Tension rod
C-30 Bearing 6002
C-31 Bearing 6205
C-32 Spacer
C-33 Spacer
C-34 Eccentric shaft
C-35 Ciecle nut
C-36 Nut
C-38 Thread
C-39 Shaft,spring
C-40 Insert
C-41 Segement
C-42 Flange,scoring blade
C-43 Flange
C-44 Set screw M8x16
C-45 Allen screw M10x25
delete the C-46
C-47 Motor A
C-48 Flange
C-49 Ball bearing
C-50 Tube
C-51 Wheel handle
C-52 Thread
C-53 Spring
C-54 Washer
C-55 Spacer
C-56 Spacer
C-57 Circle ring
C-58 Thrust bearing
C-59 Washer
C-60 Pin
C-61 Circle ring 326
C-62 Roll pin M5x28
C-63 Set screw M6x8
C-64 Roll pin A6*8
C-65 Set screw M8x12
C-66 Bearing 6002
C-67 Lock nut M6
C-68 Set screw M8x40
C-69 Washer 8mm
C-70 Hex head screw M8x12
C-71 Circle ring A20
C-72 Circle ring
C-73 Hex head screw M8x25
C-74 Hex nut M8
C-75 Pan head screw M6x12
C-76 Flat washer 6mm
C-77 Hex head screw M8x35
C-78 Sunken head screw M8x40
C-79 Hex head screw M8x55
C-80 Allen screw M6x20
C-81 Hex nut M6
C-82 Set screw M8x8
C-83 Flat key 18x35
C-84 Flat washer 8mm
C-85 Spring washer 8mm
C-86 Allen screw M8x30
C-87 Carriage bolt M10x80C
C-88 Hex nut M10
C-89 Hex head screw M8x16
C-90 Sunken head screw M6x25
C-91 Hex head screw M10x25
C-92 Set screw M8x16
C-93 Nut M35x1
C-94 Multi “v” belt 660
C-95 Multi “v” belt 560
C-96 Key
C-97 Handle wheel
C-98 Lock knob
C-101 Stop screw
C-102 Set screw M8x20
C-103 Set screw M8x20
C-105 Spring washer 10mm
C-107 Riving knife
C-108 taping screw ST4.2x10
C-109 taping screw ST4.2x26
C-110 Segement,blade guard
C-111 Lock bolt,guard
C-112 Half,blade guard
C-113 Half,blade guard
C-114 Lock washer 8mm
C-115 Knurled nut
C-116 Locking handle
C-117 Chip house
