Exploded Diagram/Parts List
51
Diagram/List F
NO. DESCRIPTION
F-1 Fence carrier
F-2 Eccentric ring
F-3 Lock rob
F-4 Flange
F-5 Bolt guide B
F-6 Bolt guide A
F-7 Bearing
F-8 Lock lever
F-9 Eccentric gear
F-10 Spacer
F-11 Pointer
F-12 Pan head screw M4x8
F-13 Lock nut M8
F-14 Roll pin A8x60
F-15 Set screw M6
F-16 Spring washer 10mm
F-17 Allen screw M10x25
F-18 Set screw M10x12
F-19 Lever
F-20 Adaptor A
F-21 Adaptor B
F-22 Fence rail A
F-23 Fence rail B
F-24 Roll pin 5x35
F-25 Roll pin 5x20
F-26 Set screw M10x80
F-27 Allen screw M10x80
F-28 Hex nut M10
F-29 Scale
F-30 Fence
