Axus YB-24S3EF4 - Before You Begin; Unpacking & Checking the Equipment

Hardware Operation Manual
7
B
B
B
e
e
e
f
f
f
o
o
o
r
r
r
e
e
e
y
y
y
o
o
o
u
u
u
b
b
b
e
e
e
g
g
g
i
i
i
n
n
n
Unpacking & Checking The Equipment
Before unpacking the RAID SYSTEM, prepare a clean, stable surface to put on the
contents of your RAID SYSTEM shipping container. Altogether, you should find the
following items in the package :
Fibre to SAS RAID system
 RAID System x1
 RAID system Hardware Installation Guide (CD media )
 RAID system Software Operation Manual (CD media )
 RS232 cable x1
 Power Cord x 2 ( 24Bay x 3)
 FAN x 1
 HDD tray x 1
 Mounting screws (bag) ×1
SAS to SAS RAID system
 RAID System x1
 RAID system Hardware Installation Guide (CD media )
 RAID system Software Operation Manual (CD media )
 RS232 cable x1
 Mini SAS to Mini SAS Cable x 1
 Power Cord x 2 ( 24Bay x 3)
 FAN x 1
 HDD tray x 1
 Mounting screws (bag) ×1
To avoid the unmatched cable between the Fibre HBA in the Host and
Fibre-SAS RAID SYSTEM, Fibre-SAS RAID system doesn’t include the Fibre
interface with the standard configuration. There are many different kinds of
Fibre connectors on varied of Fibre HBAs.
