6
INSTALLING & PROGRAMMING
THE AX-ADGM04
Attention! The AX-ADGM04 will work with both the AX-ADBOX1 and AX-ADBOX2 interfaces,
but programming will be different. Refer to the proper page for whichever interface is being
used. Also note, the programming instructions for the AX-ADBOX2 reflect gen. 2. If installing a
gen. 1 AX-ADBOX2, refer to the AX-ADBOX1 programming instructions. Gen. 2 interfaces can be
distinguished by a blue reset button between the (2) connectors.
AX-ADBOX1
Installing the AX-ADGM04
With the key in the off position:
•
Connect the 16-pin harness with stripped leads, and the AX-ADGM04 harness, into the interface
.
• Connect the AX-ADGM04 harness to the wiring harness in the vehicle.
• If an ASWC-1 (sold separately) will be used, do not connect it until the AX-ADGM04 is
programmed and fully functional.
Programming the AX-ADGM04
Attention! If the interface ever loses power, the following steps will need to be performed
again. Please ensure that the owner of the vehicle knows this.
•
Turn the key (or push-to-start button) to the ignition position and wait until the radio comes on
.
Note: If the radio doesn’t not come on within 60 seconds, turn the key to the off position,
disconnect the interface, check all connections, reconnect the interface, and then try again.
• Turn the key (or push-to-start button) to the off position, then to the accessory position.
Test all functions of the installation for proper operation, before reassembling the dash.
Note: To use fade in digital amplified models, ensure the radio is turned up 3/4 of the way.
Continue to Adjusting the AX-ADGM04
12-pin pre-wired ASWC-1 harness:
This harness is to be used along with the optional ASWC-1 (sold separately) to retain steering
wheel audio controls. If the ASWC-1 is not being used, disregard this harness. If the ASWC-1
will be used, please refer to the ASWC-1 instructions for radio connections and programming.
Disregard the harness that comes with the ASWC-1.
DIN jack:
The DIN jack is to be used with the optional AX-LCD (sold separately) to retain satellite
radio information for models that do not retain this information in the driver’s information
center. The AX-LCD can also be used to view which factory sources are active; rear seat
entertainment, satellite radio, AUX-IN.
CONNECTIONS TO BE MADE (CONT.)
