EXPLODED VIEW
1. Front cover
2. Front guard
3. Fan nut
4. Fan blade
5. Guard nut
6. Guard clip
7. Rear guard
8. Power cord
9. Long tube
10. Base
11. Remote control
12. Short tube
6 5 4 3 2 17
1. WiFi button
2. Timer indicator
3. Mode indicator: Normal, Nature, Sleep
4. Swing, left/right indicator
5. Fan speed
6. Swing button
7. Angle button
8. Left/right button
9. Mode button
10. Timer setting button
11. Fan speed button
12. ON/OFF button
MAIN PANEL 6. SPECIFICATION
1
2
3
4
5
6
7
8
9
11
10
12
11
9
10
12
8
Rated voltage 220-240V
Rated frequency 50 Hz
Rated power 65W
Noise ≤67 dB
Dimensions Tall fan:
45 × 40 × 136 cm
Short fan:
45 × 40 × 98 cm
Weight ca. 7,05 kg
Environment 0 to +40 °C
relative humidity
90 % (25 °C)
Functions
• WiFi-controlled (iOS/Android)
• 3 fan speeds
• 3 fan modes
• Vertical oscillation: -8°, 0°, 10°, 20°, 30°,
40°, 50°, 60°, 70°, 80°, 90°
• Horizontal oscillation can be adjusted to
any angle by hand (360° horizontal)Mit
• LED display and timer
Remote Control
The remote control requires one CR2032 3V
button battery (included). Insert the battery
into the remote control paying attention to the
correct polarity. Please replace the battery if
the RC is not used for an extended period.
