G
34 | 35
Nozzle
Water tank
Aroma chip
Knob
Water tank cover
Indication light
Power cord
1.
2.
3.
4.
5.
6.
7.
1
2
3
4
7
6
5
PARTS DESCRIPTION
OPERATION
1.
1)
2)
3)
4)
2.
1)
2)
3)
4)
5)
Operation condition
The working environment for humidifier is when temperature is between 5 ˚C to
45 ˚C degrees Celsius, and relative humidity is lower than 80 %RH.
Keep machine working under low mist level when room relative humidity is higher
than 70 % or in an enclosed room space.
Use clean water lower than 40 degrees (pure water is recommended).
Clean water tank and water flume when use again after a long time.
Operation steps
Get the water tank out of the machine, unscrew the water tank cover and fill the
tank with water, then screw back the water tank cover tightly . Put the water
tank on the machine base steadily.
Inspect whether the mist outlet nozzle is put well on the water tank.
Plug in the power, turn the knob clock wisely ., machine starts to work. To
adjust the mist output from minimum to maximum by turning the knob clock
wisely. To adjust the mist output from maximum to minimum and to turn off the
machine by turning the knob counter clock wisely.
When out of water, the indicating light turns red and the machine stops working .
Refill the tank then turn on the machine to have machine work again.
During the machine working, machine will stop working when take off the tank,
put tank the water tank to the machine base, machine will continue to work.
CLEANING AND STORAGE
Before cleaning, turn the functional knob point to “OFF”, take off the plug.
Transducer
The water quality in someplace is too hard so that the transducer surface will be
easy to scale formation, the users need to clean transducer with cleaning agent.
Add little cleaning agent on the transducer surface (More or less depends on the
scale ), then infuse water into the sink to soak the sink fully for 10 - 15 min.
Don’t clean transducer by any metal or stiffness material or scrape it to avoid any damage.
Water tank inside
Clean water tank inside and water sink twice per week at least when use machine
frequently. Use soft cloth wipe it when water tank side has scale. There will be some
dirt stick to the tank inside wall, which can be cleaned with soft scour, Clear the
scour completely.
Don't put acid, alkalescency, blencher scour into water tank to avoid damage.
Water sink inside
Take out the water in sink, Clean the scale by brush, then wiped by damp cloth.
Flush it by water.
Don’t pour water in sink directly when cleaning the water sink inside.
Don’t use acid scour to wash the water sink inside to avoid damage on transducer.
Storage
Drain out water in tank and body, clean the dirt, wipe out water and airing the machine.
Ensure that no water in the machine and put it to the carton.
Storage the package in dry place.
TECHNICAL DATA
Model
Main Supply
Frequency
Output
Protection Class
Water Tank Capacity
Rated Max.Moisture Capacity
17.
18.
remove the plug from outlet. Do not pull the cord to
disconnect the plug.
Do not use the appliance in wet or damp locations such
as bathrooms.
Don’t put sundries into the machine
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Ensure that the appliance is switched off from the
supply mains before removing the guard.
unplug the appliance during filling and cleaning
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Read carefully all instructions before using.
Connect to a main power supplier of 100-240 V ~
50 / 60 Hz only.
Keep the appliance and cable away from sources of
heat, sharp objects or anything that may cause damage.
Do not place the cord under carpets. Do not cover the
cord with small clothes, shirts or other similar elements.
Place the cord away from traffic areas in order to avoid
any risk of tripping over.
Do not operate the appliance if the cable or plug damaged.
Do not cover the machine during using.
Always operate on a stable flat horizontal surface.
Ensure the appliance is switched OFF before
connecting to the mains power supply.
Always ensure that hands are dry before operating or
adjusting any switch on the product or touching the
plug and mains supply connections.
Do not leave this appliance unattended when it’s in
use. Turn off and disconnect the appliance when you
leave the room for an extended period.
Switch off the appliance and unplug from the mains
socket when not in use, before filling, cleaning or other
maintain.
To disconnect the appliance, switch it “OFF”, and then
SH201
100-240 V~
50 / 60 Hz
25 W
II
3.5 L
≥ 300 ml/h
