AYR 752 - Connect Data Wire to Screen; Mount Digital Door Viewer Case

13
EN
• 3. The data wire should be fully plugged in at the back of the screen;
excess wire should be gently placed into the groove at the back of
the screen.
• 4. Hook the digital door viewer over the bracket at the top of the
locking plate and secure the digital door viewer case with the locking
bolt. (FIG. 4)
DIGI TALD OORV IEWE R
Wire image BUS
DOWNWARDS
hang
door
screw
Installation
