Guidelines and operation of this device
1. moving mirror
2. projection output and adjustable focus
3. ventilation slot
4. cooling fins
5. mounting bracket with tightening knobs
6. DMX output via 3-pin XLR
7. DMX input via 3-pin XLR
8. eyelet for optional safety cable
9. power output (unprotected, max. 9 A)
10. power input with fuse holder
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials:18-02-2017 RV Revision date and author's initials: -
4
5
6
7
8
1
3
2
9 10
