Operation and mounting
To activate the device, plug it into a mains socket. Once it's connected to an active power source, it will turn
on automatically.
During calibration, ‘AYRA’ will be shown on the display, which means the device is not ready to be operated.
Once the device has fully started up, it will jump to the last-used mode. Operation modes and other settings
shown on the display can now be adjusted or changed by means of the menu buttons.
Should the device detect a DMX signal, it will automatically switch to DMX mode and will display the last-
used address. For new devices, this will normally be DMX address 001. Of course, you can change the DMX
address via the display using the menu buttons.
Using the display and the menu buttons, you can adjust the functions and settings of the device. Press 'enter'
to confirm an adjustment or select a function, use ‘up’ and ‘down’ to change amounts and ‘menu’ to go back
to the menu. By holding the ‘menu’ button down for 2 seconds after saving a specific setting, the device will
return to operation mode and adopt the setting. This will also be done after any changes in the operation
mode or DMX address. This operation is not always necessary, considering the device automatically does
this after a new setting is confirmed.
The menu contains the following options and functions
display Mode Function
ADDR / A001 DMX address configuration Address A001 … A512
CHND Channel mode selection 2CH/3CH1/3CH2/4CH/5CH/6CH/9CH
SLND Slave mode Master
Slave
SHND Automatic mode Fade – FA00 – FA99 speed selection (press
Enter for D000 – D255 dimmer level)
Show – music-activated mode
Colo – COL1 – CO63 colour preset (press Enter
for D000 – D255 dimmer level)
Jump – JU00 – JU99 speed selection
SOUND Sound-controlled mode Mode: ON / OFF
SENS Sound sensitivity 0 - 100: sensitivity in %
BALA Colour balance basic colours RED: correction red 50 – 255
GREE: correction green 50 – 255
BLUE: correction blue 50 - 255
LED LED Display on/off when not in
use
ON/OFF
DISP Display inversion Display inversion, displ - dslp
TEST Test mode The test program runs through each LED colour
one by one to check they are all functioning
correctly
TEMP Temperature in degrees Celsius 0 ~ 9999 temperature indicator
HOUR Time registration 0000 – 9999 usage in hours
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials:24-01-2017 RV Revision date and author's initials: -
