Guidelines and operation of this device
1. light output with transparent protective cover
2. tightening knob mounting bracket
3. LED display with menu buttons
4. microphone for sound-controlled operation modes
5. 3-pin XLR DMX input
6. 3-pin XLR DMX output
7. power output for linking multiple armatures (IEC C13)
8. power input with built-in fuse holder (IEC C14)
9. safety eyelet for optional safety cable
10. mounting bracket
11. ventilation slots
Please note: The image on this user manual shows the Flash 60 LED stroboscope. The Flash 30 LED has
the same connections and functions, but they are partly located in a different place.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -
2
4
5
6
7 8
9
1
3
10
11
11
