Bear in mind that the installed fuse in the Flash 30 / 60 LED is designed to only protect the device itself. The
power output is not protected.
Installation and connection requirements
Now that you know how the Flash 30 / 60 LED works, it's important to know how to use it correctly and
safely, according to the installation and connection requirements.
Make sure the device and connection cables are out of reach of children, and that if children are present,
they are under adult supervision at all times. Because this device can be used upright or suspended, children
could pull on the cables, causing the device to fall on top of them. To avoid injury, it is important to pay close
attention to the position and/or installation of this device.
Upright use
The Flash 30 / 60 LED is not suitable for use in an upright position, unless the mounting bracket is attached
to a stable surface like a floor stand or a metal foot with sturdy materials.
Suspended use (bracket)
If you want to suspend the Flash 30 / 60 LED, use the mounting bracket that has already been attached to
the device. Use the tightening knobs to adjust the bracket.
The Flash 30 / 60 armature is already equipped with a hanging bracket and contains holes to mount a
standard G-hook or coupler. You can find standard hooks and/or brackets for 35 or 50mm tubes (truss or
light stand) at your local dealer.
Hardware for mounting the Flash 30 / 60 LED to the wall, ceiling, or beam is not included. Contact a
specialist if you're not sure which hardware is required for your situation. A wooden beam and stone wall
require different mounting methods.
Should you want to suspend the Flash 30 / 60 LED, you will need to attach a safety cable to the armature.
This is not included, but is available at your local dealer. The Flash 30 / 60 LED is equipped with an eyelet for
hooking safety cable. Once it's hooked on, you can wrap the cable around the truss or light stand and attach
it again by means of the same hook. This ensures the device is secured and prevents it from falling, even if
one or both of the brackets should come loose.
Ensure that the safety cable has a load capacity of 10x the weight of the armature and that the device can
not fall farther than 30 cm. You can wrap the safety cable around the truss or light stand several times to
ensure the fall is as short as possible. The shorter the fall, the less chance of damage or injury.
Light source
The Flash 30 / 60 LED has powerful LED modules that create an even more powerful effect thanks to a
special lens that bundles the beams together. Never look directly into the lens from at close range, as the
human eye can't adjust to the sudden intensity of the beam of light this device produces. It won't result in
permanent damage, but it can cause temporary blind spots, which may cause disorientation and discomfort.
Cooling
The Flash 30 / 60 LED is not equipped with active cooling by means of fans. Cooling the light source is done
by means of a passive cooling block and ventilation slots in the housing.
Parts and repair
This product does not include spare parts and can not be repaired by the user. All inspections and overall
maintenance should be done by a specialist.
Cleaning and maintenance
Clean the exterior of this device monthly with a dry, or slightly damp microfibre cloth. Ensure that the device
is unplugged before cleaning it.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials:02-02-2017 RV Revision date and author's initials: -
